6-Channel Class-D Amplifier 8ch DSP
6x 80 watts RMS @ 4Ω
6x 130 watts RMS @ 2Ω
Dimensions: 150 x 45 x 250 mm
6x 80 watts RMS @ 4Ω
6x 130 watts RMS @ 2Ω
Dimensions: 150 x 45 x 250 mm
Purchase
If you are interested in buying this item please contact us via our contact page.
$15 Flat rate shipping*
Description
xMusway M6v4 6ch Amplifier with 8ch DSP
The M6v4 model can surely be seen as a new milestone in amplifier construction. It is barely imaginable that a fully grown class D amplifier works in this small housing, featuring six pairwise bridgeable outputs, each with 130 watts RMS per channel (at 2 Ω). A total of 780 Watts RMS are available. The compact dimensions are made possible by an elaborate 4-fold laminated board, which also effectively suppresses EMC interference due to the favorable topology - a must, especially for full-range Class D amplifiers.
The centerpiece is the state-of-the-art DSP chip ADAU1452 from Analog Devices, which was fine-tuned by the MUSWAY engineers and leaves no audiophile wishes unfulfilled. The amplifier finds its connection via a space-saving cable harness with ISO plugs, individual Plug+Play cable sets are also available. Useful additional features include soft-clipping to protect the electronics and speakers in 2 Ω operation and the newly developed high-level input with Error Protection System. When connected to an OEM factory radio the Error Protection System ensures that no functions are impaired or error messages are written into the vehicle memory.
Features
-
Intelligent High Level Input (Error Protection System)
-
Start-Stop ready, Auto Turn-On
-
64bit, 295 MHz DSP technology, controllable via new V3 PC software or V3 App
-
Soft-Clipping (power attenuation) in 2 Ohm operation
-
Signal-to-noise Ratio ≥90dB
-
Frequency Response 15 Hz – 22 kHz (-3dB)
-
THD ≤0,1% (1 kHz, 4Ω, 90% Power)
-
Separately controllable input sensitivity (Channel 1-4, Channel 5-6), Clipping LEDs
-
Plug+Play with vehicle-specific cable sets
-
External Bluetooth® USB-Dongles BTS, BTS-HD & BTA2 for Audio Streaming & App Control (optional)
-
Digital remote control DRC1 with OLED display for controlling various DSP functions (optional)
-
Quick Connect Terminal to connect MUSWAY Subwoofer Systems
What’s included
-
1 x M6v4 DSP Amplifier
-
1 x 1,5 m USB Cable
-
1 x 20-pole Cable Adapter (High Level Inputs, Speaker Outputs)
-
1 x 6-pole Cable Adapter (Inputs CH5/6, REM IN/OUT)
-
1 x 4-pole Cable Adapter (Speaker Outputs)
-
4 x Mounting Bracket incl. Screws
-
1 x Owner’s Manual (English/German)
-
1 x 40 A replacement fuse
-
1 x 4 mm hex key
Specifications
|
Power output (RMS) @ 13.8 VDC, 1% THD |
6 x 90/160 Watts RMS @ 4/2 Ohms (DHR) 6 x 80/130 Watts RMS @ 4/2 Ohms 3 x 260 Watts RMS @ 4 Ohms bridged |
|
Crossover |
Full / Hi Pass / Lo Pass / Band Pass |
|
Crossover type and slope |
Bessel / Butterworth / Linkwitz @ 6/12/18/24/30/36/42/48 dB |
|
Crossover frequency |
1 Hz step @ 20 Hz - 20kHz |
|
Output Equalizer |
31-Band Parametrical Equalizer ±15 dB |
|
Dimensions without brackets |
150 x 45 x 250 mm |
|
Weight |
1.6kg |
|
|
|
For more information, please visit the manufacturer's website.
